HR2000 80GHz Radar Level Sensor

The HR2000 is a high-precision, ultra-low-power millimeter-wave radar level sensor designed by Holykell. Featuring a proprietary radar ranging algorithm and a user-friendly PC interface, it ensures high accuracy, sensitivity, and seamless integration. With non-contact measurement technology, it minimizes contamination and maintenance. Ideal for industries like chemicals, oil and gas, wastewater, and food processing, it supports remote monitoring and easy integration into automation systems.

AUD 0.00
Add to Cart Add Compare
Email a Friend Print
main product photo

Description

The HR2000 is a cutting-edge, high-precision millimeter-wave radar level sensor designed and developed by Holykell. It boasts ultra-low power consumption and leverages a proprietary radar ranging algorithm for unmatched measurement accuracy and sensitivity. Equipped with a visualized PC interface, the HR2000 delivers superior interaction performance, making it highly intuitive and easy to integrate into various systems.

This sensor employs advanced non-contact measurement technology, eliminating the need for physical contact with the substance being measured. This not only prevents contamination but also significantly reduces maintenance requirements, ensuring long-term reliability and efficiency. Its robust design allows it to perform exceptionally well in challenging environments, including those involving chemicals, oil and gas, wastewater treatment, and food processing.

The HR2000 is versatile and suitable for measuring liquids, distances, and levels in a wide range of applications. Its seamless integration with control and automation systems makes it a valuable tool for modern industrial processes. Additionally, the sensor supports remote monitoring and control, enabling users to enhance operational efficiency and maintain real-time oversight of critical measurements. Designed with performance, durability, and ease of use in mind, the HR2000 is an ideal choice for industries seeking reliable, high-precision level sensing solutions.

Description
Specification

Specification

More Informationnn
Box Size (Length X Width X Height) Ø125.5×76mm(for measuring water), Ø131.5×76mm(for measuring oils)
Material PVDF(Anti-corrosion type) and PA6 nylon + Fiberglass
Power supply 12-30Vdc(Regular type) 3.3-5.5Vdc(Low voltage & low power consumption type)
Temperature -40~85℃
Measuring Range 0.2-10m; 0.2-20m For measuring range >10m, it supports 4-20mA+RS485 and regular power supply only
Accuracy Distance measuring accuracy: ±10mm(typical), ±2mm/±5mm(customized)
Output 12-30Vdc: 0-5V/0-10V/4-20mA+RS485 Modbus RTU 3.3-5.5Vdc: RS485 Modbus RTU only
Protection Level IP67/IP68(3 bar) optional
Working pressure -1~3bar
Analog 0-5V/0-10V/4-20mA accuracy 0.25%F.S(typical), 0.1%F.S(customized)
FOV angle 8°
Center frequency 80GHz
Communication rate Default 9600bit/s
Scanning frequency 76-81GHz
Source Onesense
