Outdoor Asset Tracker

AT101 is an exceptional outdoor tracker that utilizes GNSS and Wi-Fi AP MAC Address Scanningto provide highly accurate positioning data. Additionally, it has tilt and temperature sensorsfor more extensive data collection and application in various scenarios. The device is designedwithIP67 and IK09 ratings to cater to different environments.

AUD 0.00 +GST

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Description

• Equipped with highly-accurate GNSS positioning and cooperate with Wi-Fi positioning

• Equipped with NTC temperature sensor to enable environment detection

• Built-in 3-axis accelerometer sensor to monitor device tilt status and movement

• Support IP67 and IK09 rating protections for harsh environment application

• Built-in replaceable batteries and works for up to over 15 years without replacement

• Provide integrated structure and anti-theft design for wireless and safe deployment

• Incorporate UV protection to be suitable for outdoor environments

• Support geofencing for targeted messaging to secure the assets and area

• Multiple and switchable modes provide motion tracking, periodic tracking, and timing tracking

• Store locally 1,300 historical records and support retransmission to prevent data loss

• Equipped with NFC and Bluetooth for easy configuration

• Function well with standard LoRaWAN® gateway and network servers

• Compatible with Milesight IoT Cloud

Specification

More Informationnn
Weight	0.202000
Material	PC
Power supply	4 × 2700 mAh ER14505 Li-SOCl2 Replaceable Batteries
Installation Method	Wall Screw Mounting, 3M Tape Mounting, Cable-tie Mounting
Ingress Protection	IP67
Regulatory	CE, FCC
Environmental	RoHS
Range	Temperature: -40 ~ 125°C
Resolution/threshold (@ 1Hz)	Longitude/Latitude: 0.000001
Protocol	LoRaWAN®
Source	Onesense
Temperature	0.1°C
Battery	Twice Daily Location Updates - 15+ Years
Position Accuracy (CEP)	5.0m (Direct Line of Sight)
Time To First Fix	Cold Start: 37s Average Hot Start: 1s Average
Wi-Fi Positioning	Indoor asset location using Wi-Fi access point scanning (device does not connect to Wi-Fi)
Wi-Fi Parameters	BSSID, RSSI
Wi-Fi Standard	802.11b/g/n 2.4GHz
Device Motion Status	Normal/Tilt
Power On & Off	NFC, Power Button (Internal)
Configuration	NFC, Bluetooth® 5.3, Downlink
Advanced Feature	Geofence, Tilt Threshold Alarm, Tamper Alarm, Data Storage (1000 entries), Data Retransmission, Data Retrievability
Impact Protection	IK09
Housing & Color	PC & Black
Antenna Connector	Internal Antenna
Frequency	CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923-1&2&3&4
Tx Power	16 dBm (868 MHz)/20 dBm (915 MHz)/19 dBm (470 MHz)
Sensitivity	-137 dBm @300bps,Tracking: -167dBm Reacquisition: -160 dBm Cold Start: -148dBm Hot Start: -159 dBm
Mode	OTAA/ABP Class A
Button	1 × Tamper Button
Operating Temperature	-30°C ~ +70°C
Relative Humidity	0 ~ 95% (Non-condensing)
Dimensions	110 × 70 × 30 mm (4.33 × 2.76 × 1.18 in)
